6’’ SUBMERSIBLE PUMPS – 3 PHASE
Technical Specification
| Power Range | : 2.2 kW - 11 kW |
| Speed | : 2880 rpm |
| Head | : Upto 250 m |
| Flow | : Upto 1000 lpm |
| Voltage Range | : 380 - 415 V, 3Ph, 50hZ |
| Liquid/Max.Temp | : Clear Water / 33°C |
| Nominal diameter | : 6’’ |
| Max outer diameter | : 147 mm |
| Motor details | : Wet type, cat -B, Duty-s1 |
| Starting type | : DOL & S.D |
| Insulation | : Wet Type, Cat - B, Duty - S1 |
Features
- Inbuilt with TOP
- Compact in Size
- Designed wide voltage operation
- Easy to Install
- Brass Impeller
6’’ SUBMERSIBLE PUMPS – 3 PHASE
6’’ SUBMERSIBLE PUMPS – 3 PHASE
6’’ SUBMERSIBLE PUMPS – 3 PHASE
6’’ SUBMERSIBLE PUMPS – 3 PHASE
